TIM-94N Universal Input Digital Indicator With Alarm Unit - Gunadaya Solutech

• Universal input digital indicator for standard signal, Temperature, Humidity, Pressure and process.
• 3 Alarm relay output.
• Input signal for :
– Thermocouple
– RTD (PT100)
– Current analog : 0-20 mA, 4-20 mA
– Voltage analog : 0-5 VDC, 1-5 VDC, 0-10 VDC
• 5 Digits 7-Segment display 0.56”.
• RS-485 MODBUS RTU protocol for communication.
• LED Status for alarm and communication.
• 4-20 mA / 0-10 VDC Transfer output.
• Lock function for protect setting program.
