- Star Delta Timer for Start Motor
- Can set the delay time from 0.3 – 120 seconds
- Pause Time from100-1,000mSec. For space between Star and Delta.
- Can use both AC and DC Supply.
- Small, compact Easy install on DIN RAIL
- With LED indicating the working status of Star and Delta
PF – 01 is a Star Delta Timer for start motor in 3 phase system
to help reduce peak current during the motor start turning. Causing
the current used in the Start Motor to not exceed the limit of the
Lock Rotor current or to help prevent electric shocks during the Start
Motor in the event that the Motor is large
