Description
• Shows Frequency, Speed and Line Speed value
• Display by 7-Segment 5 Digits  0.56 inches
• Receive input from Proximity Switch, Photo Sensor, Encoder both NPN, PNP and Pulse
• 3 Relay Output with 4 Alarm Function
• Lock Function block Setting changed from screen
• Transfer Output แบบ 4-20mA และ 0-10VDC (Option)
• Communicate with Computer via RS485 MODBUS RTU Protocol Port
• Can set number of  Pulse : round and Radius
• Able to save maximum and minimum
• Digital Input to Reset values
