Description

• VPM-06 is Relay for protect Over-Under voltage, Unbalance Phase, Phase loss and Phase Sequence.
• Accurate measurement True RMS.
• Display voltage by 7-Sagment LED 3 Digit 0.39 inches.
• Easy process for usage.
• Output Relay 5A, 250VAC, SPDT 2 CH.
• DIN Rail Installation.
• LED show relay output status and voltage status.
• Check irregular condition of voltage to view historical data and record time of incident.
• Hold Alarm for checking the time of trip to hold until reset.
• Relay operation system isolated 2 Channels.
