- Read information that is characteristic of electricity 4 – 20 mA or 0 – 10 VDC voltage, convert to 8 – bit digital data with 4 channels
- Display performance with LED Power Supply ( Green ), Run ( Orange ), and Alarm ( Red )
- There is 1 Relay Alarm when there is a communication error.
OPERATION
RMN – 005 is a signal reading device 4 – 20 mA. Or 0 – 10VDC, then converted to 8 – bit resolution data and send data to 2communication lines using RMN -006. Analog Output Driver 8- bit resolution can communicate via 2 – wire
by using with RMN-006 as the following figure below
