KM-24-M

KM-24-M is 1 phase electrical meter
Can install meter more than 127 per 1 system RS485
Can measure voltage (V), Current (A), Power(kW), Electrical energy (kWh) and display result of water usage in cubic metre (m3) unit from Pulse of Water Meter.
Input for receive pulse from water meter to send data water usage with cubic meter unit.
Electrical measure in True RMS has high accuracy.
Voltage measure range 110-240 VAC.
Current measure range 0.02 – 45 A
7-Segment LED display.
Communication is RS485 Modbus RTU Protocol.
Can set Input filter time since 0.00 – 10.00 Se
