DESCRIPTION
• Power circuit 3 phase power Supply relay, S00VAC
• Can be used with load types.
– Zero Cross (Resistive Load) : Heater, Lamp
• Input voltage : 6-30VDC and 90-240VAC
• Current : 40A, S0A, 75A
• Suitable for ON / OFF jobs often.
– There is no contactor, so there is no spark in the contactor.
– long service life

OPERATION
PST-Series (3 Phase Solid State Relay) : 3-phase solid-state relay. When the input signal of the control voltage Output will work simultaneously with 3-phase internal consisting of Semiconductor
no contactors make no arcs. Suitable for ON/OFF frequently.Available in both Resistive Load and Heater, the bulb can be used
as a replacement for the Magnetic Contactor, which provides longer service life
Due to frequent contact and high current Therefore, the installation of Solid State Relay must be installed with Heat Sink for cooling
