DESCRIPTION
• Cooling fan for installation on the roof of control cabinet or electric cabinet.
• It acts as a hot air blower and blows hot air out to the outside of the cabinet, resulting in better heat dissipation.
• High air volume (m3/ h) reduces the temperature inside the cabinet.
• IP 44 protection

OPERATION
PMB – Series is a cooling fan for mounting on the roof of the control cabinet, electronic cabinet. Or a cabinet with electrical or electronic equipment inside the cabinet by suck and blow hot air exit to the outside of the cabinet, which is usually heated to float from the bottom up. Installation of PMB-Series fans will improve the cooling of the cabinet
In addition, the installation ofthe  PMF – Series dust filter is below. To be the air from the outside into the cabinet. The heat transfer inside the cabinet is good and removing the dust filter is as easy as installing the figure A
