DESCRIPTION
• Convert weight or voltage from Load Cell (Strain-Gauge) to be Digital anoalog signal with Display to easy for operation.
• Receive input from Strain-Gauge 1.5, 2, 2.5, 3, 3.3 mV/V by Excite Voltage 5V or 10V.
• Standard analog output.
– Voltage : 0-10 VDC
– Current : 4-20 mA
• Input and Output seperate from each other (Isolation).
• Input and Output can adjust source with High-Low Limit by Push Button. It can set Range to convert signal as require.
• Can program to choose Output to operate in Direct or lnverse.
• Display shows Digital 7-Segment 1 row 6 digits can display signal result from Input and Output.
• Function Peak Hold show maximum and Tare Zero
• Digital Input for Contact command.
• DIN Rail Mounting Installation.
• 3 Alarm Relay Output 4 Alarm Function
• Decimal 4 position.
• Sensor correction -199999 to 999999 to adjust Input.
• Can communicate Computer via RS485 MODBUS RTU Protocol
